Skan Inc is India’s leading manufacturer of medical, hospital and pharmaceutical equipments instruments as well as disposable. The company was incorporated at Mumbai (India) during 2000. The company’s unique name is an amalgamation of Search, Focus and Security.
At Skan Inc we proudly say we are awardees of BHARTIYA UDYOG PRATIBHA AWARD as well ISO 9001-2008 company. We offer one stop solution for hospital set ups right from simplest hospital furniture to the most sophisticated operation theater equipments.
Our concentration and dedication in providing products as per the requirement of medical professional and Pharma industry too. Skan Inc is well known in the industry for the product quality and prompt, efficient and timely after sales service.
APPLICATIONS
- Equipped with superior quality double stage, tapered fan vaccume motors.
- Precision metering system.
- Least possible wetness on floor.
- Easy to clean, detachable, non corrosive.
- High grade chemical solution tank with 5 ltrs capacity.
- Suitable for hospital & pharmaceutical industries.
- Special designed intake air filter to prevent dust/dirt & chemical, helps to protect motor.
- Sterile areas ready for the within 1-1/2 hr max.
Specifications & Applications
| Industry | Application Areas |
|---|---|
| Hospitals | Operation theaters, ICU, NICU & Pathology labs etc. |
| Pharma & Biotech | Micro labs, production units, injectable mfg, vaccine mfg, CRO, tissue culture labs, QA/QC areas, IV fluids, medical device mfg units & animal houses. |
| Food | Production & packing areas of dairy, storage tanks, water treatment plant etc. |
| Hatcheries & Poultries | Suitable for hatcheries and poultry farming applications. |
Technical Specifications
| Parameter | Specification |
|---|---|
| Consistent Particle Size Generation | 0.3 - 1 Micron |
| Reach | 40-45 ft & 15-20 ft Height Cover |
| Space Treatment | Up to 12,000 - 15,000 Cu.ft. |
| Chemical Fogged | All Water Based Disinfectant |
| Motor | 26,000 RPM, Double Stage with Tapered Fans |
| Motor Safety | Thermal Overload Protection Against Motor Burn Due to Overheat |
| Input Power | 220V AC, 3.5 Amp, 50Hz |
| Nozzle Assembly | 304 Stainless Steel & Absolutely Non-Clogging Vortex Design |
| Power Head | High Grade Engg Plastic & Unbreakable |
| Solution Tank | 5 Litre (MOC - HDPE) Graduation Marking SS 304 Tank Available (Optional) |
| Strainer & Handle | 304 Stainless Steel |
| Precision Metering Systems | Discharge Capacity 0-90 ml/min |
| Intake Air Filter | Excellent Design with Double Layers for Primary & Secondary Filtration to Prevent Dust/Dirt and Absorb Moisture from Air |
| Empty Weight | 5 Kg |
